The init configuration is usually taken care of by setting INIT_MANAGER and systemd is the default since: https://git.openembedded.org/openembedded-core/commit/?id=0b4061c5d50261f826d0edb4b478d2d305274b7c so none of this should be needed, hopefully it will fix CI runs which currently fail with: https://github.com/agherzan/meta-raspberrypi/actions/runs/23234236947/job/67698405693 ERROR: Nothing PROVIDES 'systemd' (but /tmp/tmp.aSbUL7oQb7/openembedded-core/meta/recipes-core/psplash/psplash_git.bb DEPENDS on or otherwise requires it) systemd was skipped: conflicting distro feature 'sysvinit' (in DISTRO_FEATURES) NOTE: Runtime target 'psplash' is unbuildable, removing... Missing or unbuildable dependency chain was: ['psplash', 'systemd'] ERROR: Required build target 'rpi-test-image' has no buildable providers. Missing or unbuildable dependency chain was: ['rpi-test-image', 'psplash', 'systemd'] Summary: There was 1 WARNING message. Summary: There were 2 ERROR messages, returning a non-zero exit code. But I don't see where sysvinit would be getting into DISTRO_FEATURES here. Signed-off-by: Martin Jansa <martin.jansa@gmail.com>
meta-raspberrypi
Yocto BSP layer for the Raspberry Pi boards - http://www.raspberrypi.org/.
|
Sponsored by:
|
Quick links
- Git repository web frontend: https://github.com/agherzan/meta-raspberrypi
- Mailing list (yocto mailing list): yocto@lists.yoctoproject.org
- Issues management (Github Issues): https://github.com/agherzan/meta-raspberrypi/issues
- Documentation: http://meta-raspberrypi.readthedocs.io/en/latest/
Description
This is the general hardware specific BSP overlay for the RaspberryPi device.
More information can be found at: http://www.raspberrypi.org/ (Official Site)
The core BSP part of meta-raspberrypi should work with different OpenEmbedded/Yocto distributions and layer stacks, such as:
- Distro-less (only with OE-Core).
- Yoe Disto (Video and Camera Products).
- Yocto/Poky (main focus of testing).
Yocto Project Compatible Layer
This layer is officially approved as part of the Yocto Project Compatible Layers Program. You can find details of that on the official Yocto Project
website.
Dependencies
This layer depends on:
-
URI: https://git.openembedded.org/bitbake
- branch: master
- revision: HEAD
-
URI: https://git.openembedded.org/openembedded-core
- branch: master
- revision: HEAD
-
URI: https://git.yoctoproject.org/meta-yocto
- branch: master
- revision: HEAD
Quick Start
- source openembedded-core/oe-init-build-env rpi-build
- Add this layer to bblayers.conf and the dependencies above
- Set MACHINE in local.conf to one of the supported boards
- bitbake core-image-base
- Use bmaptool to copy the generated .wic.bz2 file to the SD card
- Boot your RPI
Quick Start with kas
- Install kas build tool from PyPi (sudo pip3 install kas)
- Set the
machine:in kas-poky-rpi.yml to one of the supported boards (see conf/machine/*.conf) - kas build meta-raspberrypi/kas-poky-rpi.yml
- Use bmaptool to copy the generated .wic.bz2 file to the SD card
- Boot your RPI
To adjust the build configuration with specific options (I2C, SPI, ...), simply add a section as follows:
local_conf_header:
rpi-specific: |
ENABLE_I2C = "1"
RPI_EXTRA_CONFIG = "dtoverlay=disable-bt"
To configure the machine, you have to update the machine variable.
And the same for the distro.
For further information, you can read more at https://kas.readthedocs.io/en/latest/index.html
Contributing
You can send patches using the GitHub pull request process or/and through the Yocto mailing list. Refer to the documentation for more information.
Maintainers
- Andrei Gherzan
<andrei at gherzan.com>
